SR55 Wide Stile and Rail Door



Door Features

  • 1-3/4” Door Thickness
  • Tubular Aluminum Extrusions
  • 6063-T6 Architectural Grade Aluminum
  • Typical 1/8” Thick Heavy Wall Construction
  • Interlocking Snap Glazing Trim - Available for 1“ or 1/4” Glass or Panels
  • Mortise and Tenon Joint with Tie Rod Assembly
  • 5” Wide Stile Hinge and Lock sides
  • 6 1/2“ Wide Stile Top Door Rail
  • 6 1/2” Wide Stile Bottom Rail
  • Optional 10” Bottom Rail

Optional 12” Mid-Panel

  • 1-3/4” Thickness
  • FRP Faced Mid- Panel
  • Insulated Polystyrene Core
  • Pebble Embossed Colored FRP Face Sheets
  • Optional Recessed Pull
  • Optional Aluminum Face Sheets
  • Aluminum Face Sheets Smooth or Stucco Embossed
  • 1/8” Hardboard Face Sheet Backing for Aluminum Faces

Color Options

  • Class 1 - 7 Mil Anodized Aluminum
  • 215 R1 Clear Satin - 313 Dark Bronze
  • Optional Kynar Painted Colors
  • Full Color Selection for FRP Face Sheets






More Aluminum Entrances



SR25 Narrow Stile and Rail Door

  • Narrow Stile Rails are popular for use as a Store Front Entrance
  • 2-1/8" Hinge and Lock Stiles
  • Various Options for top, middle and bottom cross rails.
  • Mortised and Tenon Corner Joints
  • Durable Tie Rod Joint Assembly
